Users will experience increased power capability and device speed with the Mesa 4. Memory and storage have been optimized to aid in speed. The most up-to-date Wireless and Bluetooth compatibility allows for faster data transfer speeds. The Mesa 4 is a modern stand-by device that promotes longer battery life and increases efficiency. Improvement of battery firmware has resolved issues that existed with the Mesa 3. We have also optimized our software update process to make it easier for the end user with the addition of a Device Settings app where you can manage touch profiles and more.

 The Mesa 4 maintains the Juniper Rugged standard for the entire Mesa Rugged Tablet Family, and hot-swapping capability that increases operation runtime. Customizations are also available with the Mesa 4, including configurations for a keyboard, RFID and barcode scanner.

The Mesa is used for a wide variety of applications in industries including natural resources, environmental conservation, geospatial, industrial, mining, manufacturing, utilities and public services, commercial and research agriculture and others that require an ultra-rugged tablet. For additional information, visit our industries pages.

The Mesa 4 runs Microsoft Windows 11 Pro.

The Mesa 4 comes with an included 43.2 Wh Li-Ion battery. Users can expect 8+ hours of operation time. Hot-swapping the battery can help extend battery life without disrupting workflow.

Yes, the battery provides hot-swap capability for additional runtime without disrupting workflow.

The Mesa 4 weighs between 1.5-2 lbs (680-907 g) depending on battery configuration and optional expansions.

The Mesa’s screen measures 7 inches (178 mm) diagonally and has a resolution of 1280x800.

With a best-in-class sunlight-readable screen, the Mesa 4 displays vibrant hues, crisp images, and impressive contrast to ensure visibility in all lighting conditions. We have seen 1000 NIT typical brightness at highest brightness setting.

Touchscreen profiles are an easy way to ensure high-accuracy input in any field conditions. Touch profiles are designed to meet a variety of finger, stylus, and glove inputs in varying conditions, including rain. You can read more about these profiles on our blog or watch the demonstration video here.

The Mesa 4 has a USB 3.0 port, 3.5 audio jack, 12V DC power input jack and docking port connections (power, USB 2.0, and HDMI).

The Mesa 4 rugged tablet, removeable battery (installed), stylus, stylus tether, hand-strap, 12V DC charger.

With a Mesa Rugged tablet running Windows 11 you will be able to run all the desktop-class programs on the device. This gives you the flexibility you need to have your office anywhere.

Yes, we have created expandable storage via a user-accessible MicroSDXC card slot located behind the battery.

In short, yes! The Mesa 4 is a complete computer in a compact rugged form factor. The Windows 11 OS is the same as any laptop or desktop PC. This allows you to run all your data collection apps, office software, etc. We recommend using a USB-C dock for a more traditional office experience: just sit down, dock, and work with a mouse, keyboard and monitor. When you need to hit the field, just pull it from the dock and you have your office in your hands.

Yes, we recommend using a USB-C dock or hub for docking a Mesa 4.

Yes, the Mesa 4 and Mesa 3 support our attachable keyboard accessory. This keyboard allows for quick data entry and field work. You can read about it here.

Contact Juniper Systems directly to receive pricing and ordering information.

We offer easy download of all our user manuals. Mesa 4 manuals can be found here. They are also available on the device itself. File path: C:> This PC> Program files>Juniper Systems > Manuals

IP68 and MIL-STD-810H are standards developed to test devices against simulated environmental conditions. The IP68 certification establishes that a device is resistant to water and dust. The MIL-STD-810H certification can establish versatility against a variety of tests including resistance to shock.

The Mesa line of tablets are dustproof and waterproof tested to withstand full submersion at 1.4 meters for 30 minutes. They are also shockproof tested to withstand multiple 4-foot drops to concrete.

Learn more about IP68 ratings.
Learn more about MIL-STD ratings

See our support section of our website for awesome tips on how to get the most out of your Mesa. For programing your three physical hardware buttons click the link below:

https://junipersys.com/support/article/12798

The Mesa 4 has long-range Bluetooth® Smart Ready wireless technology (v5.3 +EDR Class 1.5 with BLE support), Wi-Fi® 6 (802.11 ax) (2.4 GHz and 5 GHz Wi-Fi 6E), and 4G LTE multi-carrier capabilities.

Yes, we offer an optional built-in barcode imager and decoder.

Yes, we offer an optional built-in UHF RFID module and internal antenna. We offer region-specific frequency configurations.

Yes! The Geode Sub-meter GPS Receiver is the perfect companion to the Mesa line of tablets for sub-meter GIS needs.

The Mesa is designed from the ground up to meet not only Juniper Rugged™ qualifications but several other certifications and durability standards.

• IP68 waterproof and dustproof

• Operating temperature: -4 F to 122 F

• Storage temperature: -22 F to 158 F

• Shockproof: multiple drops from 4'

• Third-party-validated for MIL-STD-810H

Securing data has always been one of Juniper Systems’ top priorities. Often times the time effort cost and resources of replacing data due to a broken consumer device outweighs the investment of an ultra-rugged device.

Installing software on a Windows 11 Mesa is the same process as downloading software onto a tablet or desktop computer.

The Mesa Rugged Tablet family is designed and assembled in Logan, UT, USA.

Yes, the Mesa 4 is TAA compliant.
